Drillserve Ltd Mining Equipment Dealers Since 1979.
Sales Catalogue

Sales Catalogue

Sort By
Categories
Drilling Accessories
£28

R38 Button Bits
•102 mm

Over 30 available

Vat will be added to final price

For further assistance please call 01209 710079 or email office@drillserve.com

£40

SP 35 Fishtail Bit .
Includes Bit Adaptor 1 1/8 Hex
Unused old stock

20 available

VAT @ 20% will be added to final price.

For further assistance please call 01209 710079 or email office@drillserve.com

£35

SP 25 Fishtail Bit
65mm
Bit Adaptors 1 1/8 hex

50 available

Unused old stock

Vat @ 20% will be added to final price

For further assistance please call 01209 710079 or email office@drillserve.com

£80

LONGHOLE EXTENSION RODS – MALE/FEMALE
New & Unused stock
•Effective Length 1.83m
•Diameter – 38mm
•Thread HM38
•Manufacturer Bdart Canada
•Spanner Flats – Have end

Label References
– M/F 1830 39R
– HM38 WFC

30 available.

£80 each. VAT to be added to final invoice.

For further assistance please call 01209 710079 or email office@drillserve.com

Hydraulic Rotary Heads
£5000

Hydraulic Rotation head

This head has been stripped and inspected. The internals are like new. We removed it off a rig that was set up for a RC drilling job several years ago but never used.

The is no makers plate or model number on the head but it may be an early Dando head. The hydraulic motor fitted to the head is a Danfoss which runs well but again has no model number on it.

The head has through head flushing and a flush swivel fitted to the back of the head.

The thread coming out of the head matches up with 2 7/8 Api internal flush.

Please contact office@drillserve.com or call 01209 710079

£4500

Drillserve Hydraulic rotary head for 18mm square button lock through flush augers.

Robust rotary head incorporating flushing air or water supply. Simple and robust.

Rotation speed typically up to 375rm.

With OMR160 motor.

Hydraulic oil requirement 60L/M at max 175 bar.

3 New Available
£4500 + VAT each. Ex works, complete

1 Very Good Second hand
£2750+ VAT

Contact office@drillserve.com for more information

Miscellaneous
£2950

Deutz F6L912W

S/N 5379171
86hp

Running engine, removed from an underground MEWP. Starts and runs fine oil pressure 35psi on tick over 50psi @1600rpm.

Compression Test Results. 5 Second turn over:

Cylinder 1 270psi
Cylinder 2 270psi
Cylinder 3 270psi
Cylinder 4 270psi
Cylinder 5 270psi
Cylinder 6 270psi

Sold a seen.

Price excludes VAT

£5000

MetreEater BQ Pneumatic Diamond Drill

Price excludes VAT

Contact office@drillserve.com or call 01209 710079 for further information

£1000

Zoomtrack final drives and tracking motors available fully refurbished. Both left and right hands available.

Price excludes VAT

£1200

Air motor for tracking or bucket on an Eimco 21. Stripped and overhauled, new rings and bearings. Ready to go.

Price excludes VAT.

£1000

Built to our own design. Popular with rope access operators. Cross bar is 3.5 inch to accept a standard mine bar clamp.

Price excludes VAT

Pneumatic Drifters
£1800

Atlas Copco BBC100 Drifter. Refurbished.

Price excludes VAT.

£3750

Atlas Copco BBE57 drifter refurbished.

Price excludes VAT

Pneumatic Hand Drills
£1500

These drills have been stripped and checked over and any worn parts replaced. They are ready to go to work. Price includes a spares package.

Available with short or long legs.

These are also available to hire at £250 + VAT per week.

VAT to be added to final invoice.

Contact office@drillserve.com for further information.

£1200

S250 ROCK DRILL Refurbished

Boart Longyear continues on its long history of providing premium Rock Drill and Blast Drilling products for the most demanding conditions with the reinvented S250 Pneumatic Rock Drill. The S250 is the global standard for high performance, premium benefits, long lasting reliability, and the highest quality for hand held rock drills. The S250 is offered in three primary configurations, Jackleg, Stoper, and Sinker, to provide maximum versatility. Boart Longyear improves on the S250 history through using premium materials and components which are assembled to strict quality standards in Canada.

Performance
Boart Longyear’s S250 pneumatic rock drill is a high performance drill ideal for development and stoping applications where high drilling speed is a primary requirement. The S250’s size and versatility allows for drilling in confined spaces and orientations. It is designed with an ideal power weight ratio to provide optimum balance between power, mass and vibration for maximum productivity and fast penetration.

Premium Benefits
The S250’s legendary performance and reliability delivers world class productivity with fast penetration rates and minimal downtime. It provides maximum operator comfort and minimizes fatigue by offering precise leg controls, lightweight design, and an optional muffled version. The rugged design was developed for the most demanding conditions and provides durable, long lasting machine. The simple construction means easier and less frequent servicing with less opportunity for wear. The S250’s reduced part count and reduced complexity provides a more robust design as compared to competitors’ drills.

Reliability
The S250 rock drill has been commonly referred to as the ‘Bonus Drill’ because of its exceptional reliability and performance. Assembled and tested in Canada from premium materials and exact specifications, every Boart Longyear S250 rock drill is measured against strict standards for output and capacity prior to shipment to ensure that each drill delivers on performance, guaranteed.

10 available

Price excludes VAT

£1200

Alamac Gopher roof bolters. Various lengths available with refurbished rotation motors.

3 Available

VAT to be added to final invoice

Pneumatic Rotary Heads
£3500

Neumac MPL-22/005 Pneumatic Rotation Head. Fitted with a 2 3/8 api sub.

Light weight rotation head ideal for slope stabilization jobs.

Brand new with mount plate.

5 available

We also have one secondhand unit available for £2500.

All prices exclude VAT

Surface Drillrigs and Feeds
£12000

Pneumatic crawler drill rig with L550 drifter.

Year of Manufacture: Probably 1970 – no markings or CE mark

No dust collector

Good working order

Extending boom and strong tracking.

Capacity – 51mm diameter to 25m in good rock

64mm diameter to 15m in good rock

Air consumption 450 cfm at 100 psi

DRILLSERVE HAVE A FULL SUPPLY OF SPARES FOR THIS MACHINE

PRICE: £ 12,000 + VAT

RENTAL: £ 600 + VAT per week + mobilisation costs

Underground Access Baskets
£18500.00

Dimensions: Length 6.7m, width 1.3m, height 2.2m

Weight: 8160kg

Max working height to basket floor – 5.95m

Basket S.W.L. – 350kg

Capable of working on steep gradients.

Deutz F4L912W Engine.

Rubber pads on tracks.

Basket can be operated by external 110v supply or compressed air.

C E Marked

PRICE: £ 18,500 + VAT ex works including test

RENTAL: Mobilisation £1,800 including test

Delivery at cost

Weekly – £ 550 + VAT

Collection at cost

Damage charged to client

£25000

Reference BWB1/8007368

Year of Manufacture: 1995

C E Marked

Engine: HATZ 4H50TIC

Alternative power for basket movements

3 phased and compressed air

Tracking dimensions: L 7.25m W 1.75m H 2.4m

Weight: 10.5 tonne

Maximum working height: 9.4m to floor of basket

PRICE: £ 25,000 + VAT with new test certificate

RENTAL: £ 550 + VAT per week + mobilisation costs

Underground Drillrigs
£18000.00

Refurbished Price: £50,000 + VAT (fully overhauled and painted)

Price as is: £18,000 + VAT

1 available

Electro hydraulic drill jumbo

Condition:

Ex mine working order

Engine oil analysis OK

Maintenance and parts manual with machine

Year of Manufacture 1992

Number 2700 Order number 151

Operating weight 9400kg

Boom B26F/G – Extending rollover

Number 8014501A Order number 311 02/92

Feed CTEV6-10G – Telescopic with hydraulic clamp

Number 80417677 162 02 92

Operating Hours Electric 4695

Operating Hours Diesel 1176

DC Voltage 24 Volts

A/C Voltage 415

Kidde Fire Suppression

Catalytic Convertor

Length 9-10m

Width 1.7m

Tyres 7.50 x 15 – 3 with tyre fill

Rockdrill Boart HD150 S/5039/7

S5050/6CYL/S5039/7 B/H

£15000.00

Overhauled Price: £48,000 + VAT

Price as is: £15,000 + VAT

1 available

Narrow vein electro hydraulic drill jumbo

Current condition:

Ex mine running

One Hydraulic pump needs attention and cable reel need attention.

Manuals present

Year of manufacture 1991

Number 2639

Operating Weight 8400kg

Boom B14F Rollover Boom no extension

Number 80145492 Order 103.0191

Feed CC250 6EVG 1.5m rod hydraulic clamp

Number 80417752 Order 394.0191

Operating Hours

Electric 5663

Diesel 1330

Rockdrill hydrastar 200 – no serial number

DC Voltage 24 volts

A/C voltage 415

Kidde Fire suppression

Cable reel 90N5410303

Length 9m

Width 1.2m

Height 2m

Tyres 8.25 – 3 x Tyre fill, 1 pneumatic

£18320

To suit 5T excavator or bigger.

03/16 Manufacture Conformity 16/01/2017

Attaches to excavator quick hitch with manual swing dump clamp to get correct direction for drilling. Weight 335kg including controls.

Uses 41/51mm auger drilling systems with 1.5m extensions.

Fitted with flushing system for through flush if required.

CE marked and fitted with interlocking guard.

Controls operated by external 110v supply or by 12v supply from excavator.

Hydraulic supply – quick couplings from excavator breaker lines.

Drilling capacity 12 metres plus dependant on ground conditions.

Instructions and service/parts manual available.

Suitable augers and bits available.

Fully overhauled and checked.

PRICE: £ 18,320 + VAT ex works

RENTAL: Mobilisation £250 + VAT

Delivery at cost

Weekly – £400 + VAT (minimum 3 weeks hire)

Collection at cost

Damage charged to client

Underground Trucks
£18,000

15 ton underground dumper.
Ex mine condition, machine runs and drives.
Currently for sale in ex mine condition at £15,000 plus vat but can be refurbished for £32,000 plus vat.
Cut down butt for easier loading.
Hours showing 1466
Price excludes VAT
For further information please contact office@drillserve.com or call 01209 710079

Winches
££1000
Heavy duty hydraulic winch. High torque, low rpm. I ran it on my power pack and it ran at 45rpm @ 60LPM. No wire on the drum but the wire I removed was 16mm. Powered by a Danfoss OMR200 motor. The winch has a spring applied brake and has a free wheel option. Runs fine, freewheel disengages freely. Guard needs straightening or removing. Unknown manufacture and age. All I know is it would of come off some piece of mining equipment. Dimensions 90cm x 65cm x 50cm Vat to be added to final sales price. Please contact office@drillserve.com or call 01209 710079
